Micro Traxion

The Micro Traxion is a compact and lightweight progress-capture pulley designed for crevasse rescue, hauling, and self-rescue, and for use as an emergency ascender. The cam can be locked in the open position so the device can be used as a simple pulley. Sealed ball bearings provide excellent efficiency (91 %), while the device will perform even on frozen or muddy ropes.

Specs

• High-efficiency, lightweight, and ultra-compact progress capture pulley (volume and weight 50 % smaller than the Mini Traxion)
• Designed for crevasse rescue, hauling, self-rescue, and for use as an emergency ascender
• 91% efficiency thanks to sealed ball bearings
• Cam can be locked in open position so device can be used as a simple pulley
• Works on frozen or muddy ropes
• For use on ropes between 8mm and 11mm in diameter
• Diagrams for rope installation engraved on interior of pulley

Sheave Type	Sealed Ball Bearings
Sheave Diameter	25 mm
Working Load	2.5 kN x 2 = 5 kN
Working Load - Progress Capture Pulley	2.5 kN
Breaking Strength	7.5 kN x 2 = 15 kN
Breaking Strength - Progress Capture Pulley	4 kN
Weight	85 g / 2.99 oz
